Getting Started with Giraffle on TigerGraph Cloud

Getting Started with Giraffle on TigerGraph Cloud

Pre-Requirements

  • Have git && gradle installed on your computer
  • Your TigerGraphs Cloud Instance Details

Introduction to Giraffle

Giraffle can be used to help you automate the deployment of schema, loading jobs, and queries to TigerGraph

Giraffle helps you keep your code local while executing your gsql scripts on a remote server. Giraffle also helps you keep environment specific configuration out of your code. Most importantly it helps you keep your credentials out of your code.

To learn more about Giraffle, it’s suggested to check out the following, Deep Dive into Giraffle a GSQL Build Tool or Getting Started with Giraffle to learn how to use all of the Giraffle functionalities.

Setting up Giraffle on a New Project

For this tutorial we will walk you through “how-to” set up your project from the ground up.

Step 1) Create a Project Directory: Navigate to your project directory. If a project directory doesn’t exist create one, and the enter your project directory. A simple command to do this in a terminal:

mkdir yourprojectname
cd youprojectname

Step 2) Initialize Gradle: You can select “basic” and “Kotlin” as a default.

gradle init

/* It will prompt you with */
It will prompt you with:

Select type of project to generate:
1: basic
2: application
3: library
4: Gradle plugin
Enter selection (default: basic) [1..4] 1

Select build script DSL:
1: Groovy
2: Kotlin
Enter selection (default: Groovy) [1..2] 2

Project name (default: yourprojectname):

Initializing will give you the default gradle directories and files needed for giraffle and or gradle build projects.

Step 3) Add Giraffle Plugin: Add the following into your “build.gradle.kts”

import com.optum.giraffle.tasks.GsqlTask

plugins {
     id("com.optum.giraffle") version "1.3.2.1"
     id("net.saliman.properties") version "1.5.1"
}

repositories{
     jcenter()
}

To test if Giraffle is working running try “gradle tasks” you should new GSQL tasks appear

Step 4) Initialize GSQL project: There is a built-in task called “gsqlNewProject” that will setup your project directory with all the appropriate directories and files.

gradle gsqlNewProject --console=plain

You will need to have the following TigerGraph :

– Project name == Graph name

-Tigergraph Host == TigerGraph cloud hostname

-Admin Username

-Admin Password

-Username

-Password

If you’re reading this and don’t have those. Don’t worry. Check this blog out on Getting Started with TigerGraph Cloud and simply come back.

Step 6) Create a cert.txt file: This step is to prevent man-in-the-middle attacks. In your main project folder run the following but, replace hostname.

openssl s_client -connect hostname.i.tgcloud.io:14240 < /dev/null 2> /dev/null | \
openssl x509 -text > cert.txt

Step 7) Add caCert

In the file “build.gradle.kts” make sure your caCert is added:

import com.optum.giraffle.tasks.GsqlTask

plugins {
id("com.optum.giraffle") version "1.3.3"
id("net.saliman.properties") version "1.5.1"
}

repositories {
jcenter()
}

val gsqlGraphname: String by project // <1>
val gsqlHost: String by project
val gsqlUserName: String by project
val gsqlPassword: String by project
val gsqlAdminUserName: String by project
val gsqlAdminPassword: String by project
caCert.set("./cert.txt") // ADD CERT HERE
val tokenMap: LinkedHashMap<String, String> =       linkedMapOf("graphname" to gsqlGraphname) // <2>

val grpSchema: String = "Tigergraph Schema"

tigergraph { // <3>
scriptDir.set(file("db_scripts"))
tokens.set(tokenMap)
serverName.set(gsqlHost)
userName.set(gsqlUserName)
password.set(gsqlPassword)
adminUserName.set(gsqlAdminUserName)     adminPassword.set(gsqlAdminPassword)
caCert.set("./cert.txt")
}

In the same file “build.gradle.kts” add the following caCert.set(“./cert.txt”)

tigergraph {
scriptDir.set(file("db_scripts"))
tokens.set(tokenMap)
serverName.set(gHost)
userName.set(gUserName)
password.set(gPassword)
adminUserName.set(gAdminUserName)
adminPassword.set(gAdminPassword)
caCert.set("./cert.txt") // ADD CERT HERE
gClientVersion?.let {
     gsqlClientVersion.set(it)
     }
}

Time to test

Run the following task to get a GSQL prompt to appear:

gradle gS --console=plain

If everything was configured correctly you should be able to see “Welcome to TigerGraph”

Conclusion

At this point you have a fully functional TigerGraph project build that allows you to:

-Abstract your important credentials and properties

-Co-develop by pushing your code to a git-repository

-Execute GSQL commands on the server
